Description

Band saw blade width mm
Suitable for re-sharpening CV, bimetal and carbide tipped saw bands. Accessories: Coolant system encapsulated design, freely programmable tooth shapes, 1 holder for band saws, 1 grinding wheel holder. Saw band width: 8 - 80 mm, tooth pitch: 3 - 34 mm, base blade thickness: approx. 0.5 - 3 mm, saw band length: min. 1400 mm or min. 2800 mm - max selectableGrinding speed: approx. 100 - 600 mm / MinRadius wheel: ( 14F1 ) CBN or DIAGrinding wheel diameter: 200 mmmax. Grinding wheel width: 3 mm Grinding wheel bore: 32 mm Grinding motor: 0.5 kW Connected load approx.: approx. 1.5 kW (400 V / 50 Hz) Weight approx.: 370 kg Dimensions W x D x H approx.: 2000 x 1117 x 2210 mm Colour: light gray RAL 7045/dark gray RAL 7047
