Description

Suitable for end machining of blanks as well as peel grinding of steps, for creating tips, chamfers, radii and their combination at the ends of cylindrical tools made of solid carbide, HSS and ceramic. Up to four different grinding wheels in one setup. Accessories: NUMROTOplus single-user system software NUMROTOplus duty cycles workpiece (RS/SF) NUMROTOplus SF cycles software NUMROTOplus cylindrical grinding SF 40 software incl Vapor stab separator.brWorkpiece length max.: 320 mmWorkpiece diameter max.: 32 mmTool holder cone: ISO 50Grinding spindle speed continuously variable: max. 7,500 rpm, grinding wheel diameter: max 350 mmConnection value approx.: 25 KVA (400 V / 50Hz)Dimensions L x W x H: 1900 x 1900 x 1900 mmWeight approx.: 4000 kgWorkpiece weight max.: 2.5 kgTravel X-axis: 450 mmTravel Z-axis: 250 mmResolution m/min.,
