Description

Trrumpf TrumaBend V 130X

Year of construction 1999

Machine hours: approx. 58,000h

Pressing force: 1300 kN

Folding length: 3,060 mm

Basic equipment:
- DELEM control

- Upper drive concept in two-cylinder version Y1/Y2
- Electro-hydraulic tappet drive using proportional valve technology

- Stroke 365 mm,

- Installation height 535 mm
- Plunger travel measuring system with spring compensation via glass scales
- modern block hydraulics
- spherical suspension and inclination of the pressure beam
- CNC backgauge system 4 axes (Z1, Z2, R, X – CNC)
- safe finger adjustment from the front
- 2 pcs. stop fingers
- self-centering, manual, hardened upper tool holder for vertical
Tool change
- program-controlled lower tool displacement (I-axis) for 2 positions
- modern protective cover, CE mark
- Hydraulic upper tool clamping
- Hydraulic lower tool clamping
- CNC crowning
